Rain gauge with Wi-Fi

€59,00
€41,00 €59,00
Tax included. Shipping calculated at checkout.
ConnectivityWi-Fi
power supply2xAAA batteries
Installation locationOutdoors, exposed to the elements
App SupportAqua-Scope Web App
Availability: In stock
SKU: RANWIE01
EAN: 4251295783413
Aqua-ScopeWater, humidity & temperature sensor (LoRaWAN)
Wasser - , Feuchtigkeits - & Temperatursensor (LoRaWAN) - Aqua - Scope - Aqua - Scope
Regenmesser WLAN - Aqua - Scope - Aqua - Scope
€59,00
€41,00 €59,00
This rain gauge uses a tipping bucket to measure the rainfall amount at the sensor's location in milliliters and transmits this data, along with the temperature, every 15 minutes with an accuracy of 0.5 mm water column. In the event of heavy rainfall exceeding 15 l/h, a heavy rain alarm is triggered promptly. Both the heavy rain threshold and the measurement interval are configurable.
The device communicates via Wi-Fi, either to the Aqua-Scope Cloud and thus to an app on your mobile phone or PC, or via MQTT to a server of your choice, or as a JSON object, for example in Home Assistant. The device is powered by two AAA batteries. The included VARTA batteries provide a runtime of approximately two years. A low battery level is reported wirelessly, allowing you to replace the batteries before the device shuts down.

Processor:

  • Main: ESP32-WROOM_32E (Xtensa Dual Core 32 Bit, 240 MHz, 520 KB RAM)
  • Subsystem: Xtensa 16 bit Ultra Low Power RISC

Wireless connection:WIFI 2.4 GHz 802.11 b/g/n

Measurements:

  • Rain: Accuracy: 0.5 mm or 0.5 l/m3; Measurement period: 15 minutes
  • Temperature: Accuracy +/- 3 degrees; Measuring range: -25 °C … 50 °C
  • Status report: every 6 hours if no rain has fallen, otherwise every 15 minutes. Heavy rain alarm: from 15 liters/hour, threshold configurable.

User interface:3-color LED, single push button

Power supply:

  • 2 * AAA batteries
  • Voltage: 2.2 … 3.6 V

Environmental conditions:

  • Transport and storage: -65 °C … 125 °C
  • Operating temperature: -20 °C … 50 °C
  • Relative humidity: 0...90%

Water protection:IP 55

  • Dimensions: 132x132x139 mm
  • Packaging: 140x140x150 mm
  • Weight: 219 gr.
  • Detailed instructions for the installation and connectivity of Aqua-Scope products can be found here .

Do you have a question about the product? Feel free to contact us:

  • Main unit
  • 3 * Mounting screws and dowels
  • 2 * AAA batteries

Here you will find the declaration of conformity for the Aqua-Scope products.
